7.5 Object 0x47, Device Level Ring (DLR)

The Device level Ring Object contains the status information for the DLR
protocol and enables the possibility for the use of an Ethernet ring topology. The
measuring system don't support "supervisor" functionality

7.5.1 Common Services

Service Code
0x01
0x0E

7.5.2 Class Attributes

No. Access Name
1 Get Revision
2 Get Max Instance
Number of
3 Get
Instances
Table 16: Device Level Ring, Overview of the class attributes

7.5.3 Instance Attributes

Attr.-ID Access
1 Get
2 Get
10 Get
12 Get
Table 17: Device Level Ring, Overview of the instance attributes
Printed in the Federal Republic of Germany
01/27/2022
Service Name
Get_Attributes_All
Get_Attribute_Single
Data type
UINT
UINT
UINT
NV Name Data type
Network
V USINT
Topology
Network
V USINT
Status
STRUCT
of:
Active
V Supervisor UDINT
Address
ARRAY
of 6
USINTs
Capability
V DWORD
Flags
TR-ECE-BA-DGB-0102 v10
Description
Returns the contents of all attributes. The
order corresponds to the Attr.-ID. According
to the data type the Low part is written first.
Returns the contents of the specified
attribute.
Attribute Description
Revision of this object
Maximum instance number of an object
currently created in this class level of the
device.
Number of object instances currently
created at this class level of the device.
Description
Current network
topology mode
Current status of
network
IP and/or MAC address
of the active ring
supervisor
Supervisor IP Address
Supervisor MAC
Address
Describes the DLR
capabilities of the device
Default
0x0002
0x0001
0x0001
Default Page
- 152
- 152
-
- 152
-
- 153
