Steckerbelegung / Pin assignment
Cxx-115 EtherNet IP with optional heating
X1 = Port 1
EtherNet/IP IN / OUT; Female socket (M12x1-4 pin D-coded)
X2 = Port 2
1
TxD+
Transmission Data +
2
RxD+
Receive Data +
Transmission Data –
3
TxD–
Receive Data –
4
RxD–
X3
Male socket (M12x1-4 pin A-coded)
11 – 27 V DC
1
2
Do not connect!
3
GND, 0V
4
Do not connect!
X4
Optional heating - Male socket (12 pin A-coded)
11 – 27 V DC
1
2
GND, 0V
3
N.C.
4
N.C.
5
N.C.
6
N.C.
7
N.C.
8
N.C.
9
N.C.
10
N.C.
11
N.C.
12
N.C.
EtherNet/IP Addresses
TCP/IP Object Attr. 3: Config Control
0x00
0x02
TR - ELECTRONIC GmbH, Eglishalde 6, 78647 Trossingen, Tel. ++49 (0)7425 / 228-0, Fax ++49 (0)7425 / 228-33
Edition-/Rev.-Date: 10/28/2014
brown
blue
Supply voltage
Description
Flash configuration
DHCP request
Document-/Rev.-No.: TR-ECE-TI-DGB-0252-02
X4 is only available at the
variant with optional heating.
The shielding is to be connected with
large surface on the mating connector
housing!
Mating
Face
Supply
Mating
voltage
Face
Mating
for heating
Face
Page 2 of 2
