7.4.3.35 Attribute 109, Temperature High Limit
Temperature Low Limit defines the maximum value of the temperature with the
unit that is defined in "Attribute 107, Temperature Value Format" it is standardly °C. If
this value is exceeded in "Attribute 47, Warnings" the depending warn bit (14) is set to
high.
INT, Default: + 85 °C
2
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
To save this attribute permanently the attribute 112 Accept Parameter or service
code 0x16 save must be executed.
7.4.3.36 Attribute 110, Additional Vendor-Parameter 1
Reserved for further functions.
7.4.3.37 Attribute 111, Additional Vendor-Parameter 2
Reserved for further functions.
7.4.3.38 Attribute 112, Accept Parameter
Accept Parameter complies to the service code 0x16 (Save Paramter) and saves
the measuring system parameter into the non-volatile memory (EEPROM).
With write access ≠ 0 all changed attributes are stored permanently and the
acceptance of changed values for the instance attributes is performed.
Attr.-ID
Data type
Access
Lower limit
Upper limit
Default
Printed in the Federal Republic of Germany
01/27/2022
Temperature Low Limit
Byte 0
Byte 1
7
0
15
up to 2
2
0x23
Logical Type
Class #23
112
USINT
Set / Get
0
255
0
TR-ECE-BA-DGB-0102 v10
8
up to 2
0x24
0x01
Instance #1
= Instance
0x30
0x6D
Logical Type
Attr.-ID #109
=Attr.-ID
TR-Electronic GmbH 2013, All Rights Reserved
Page 149 of 175
