Additional safety instructions
2 Additional safety instructions
2.1 Definition of symbols and instructions
2.2 Additional instructions for proper use
The measuring system is designed for operation in 100Base-TX Fast Ethernet
networks with max. 100 Mbit/s, specified in ISO/IEC 8802-3. Communication via
EtherNet/IP™ occurs in accordance with IEC 61158 et seqq., Type 2 and IEC
61784-1, CP 2/2 Type 2. The device profile corresponds to the "Encoder Device
Profile 0x22" of the ODVA™ EtherNet/IP™ specification.
The technical guidelines for configuration of the Fast Ethernet network must be
adhered to in order to ensure safe operation.
Proper use also includes:
●
observing all instructions in this User Manual,
●
compliance with the Assembly Instructions, particularly the chapter "Basic
Safety Instructions" contained therein, must have been read and understood
prior to commencement of work
TR-Electronic GmbH 2013, All Rights Reserved
Page 98 of 175
means that death or serious injury can occur if the required
precautions are not met.
means that minor injuries can occur if the required
precautions are not met.
means that damage to property can occur if the required
precautions are not met.
indicates important information or features and application
tips for the product used.
TR-ECE-BA-DGB-0102 v10
Printed in the Federal Republic of Germany
01/27/2022
