Parameterization

7.5.3.1 Attribute 1, Network Topology

Network Topology Attribute returns the current type of network topology.
USINT
Access
Get

7.5.3.2 Attribute 2, Network Status

Network Status Attribute returns the network status of the measuring system
point of view.
USINT
Access
Get

7.5.3.3 Attribute 10, Active Supervisor Address

Active Supervisor Address Attribute returns the IP and MAC address of
the actual supervisor. The value "0" displays that currently no address is set.
STRUCT of:
UDINT
2
ARRAY
USINT
7
2 up to 2
 TR-Electronic GmbH 2013, All Rights Reserved
Page 152 of 175
Value Description
0 Line structure
1 Ring structure
value Description
0 Normal operation
Ring bus error
1
(only if ring structure is active)
Unexpected bus cycle occurred
2
(only if line structure is active)
Byte 0 Byte 1
7 0 15
up to 2 2
USINT
0 7 0
2 up to 2
TR-ECE-BA-DGB-0102 v10
Supervisor IP address
Byte 2
8 23
up to 2 2 up to 2
Supervisor MAC address
USINT USINT
7 0 7
2 up to 2 2 up to 2
Default
Byte 3
16 31
2 up to 2
USINT USINT
0 7 0 7
2 up to 2 2 up to 2
