e) Changing the model memory

Press the "DN" button. You are now in the programming function for switch-
ing the "model memory". By pressing the "INC" and "DEC" buttons, you can
switch between model memories 1 ("N1") to 5 ("N5"). When you change the
model memory, all functions programmed in the model memory are re-called.
To leave the menu item, switch off the transmitter or press "UP" and "DN" at
once. The settings made are saved.
Attention!
Choosing a model memory that does not fit the model may
result in severe malfunctions during flight. Attention! Danger of
damage to persons and objects! Take notes regarding which
model memory is used for which model. Mark your models to
indicate the proper model memory in your remote control
transmitter. Check before each start if the model memory
chosen fits the model used.
All settings, mixers and functions are only performed correctly
if the adjustment elements (servos, gyros, etc.) are plugged
into the receiver in a certain sequence.
Slot Receiver
CH 1 - Servo
CH 2 - Servo
CH 3 - Servo / electric setting
CH 4 - Servo / gyro
CH 5 - Servo / gyro
CH 6 - Servo
CH 7
CH 8
* The "HP2" mode corresponds to the so-called "home mechanics" (roll and pitch with 2 servos)
** Here you can connect the tail servo or a gyro
*** Only for changing gyro sensitivity
158
Function HP1
Swash plate Roll
Swash plate Pitch
Engine Engine
Yaw** Yaw**
Aux*** Aux***
Swash plate Pitch
(not assigned) (not assigned)
(not assigned) (not assigned)
HP2* HP3
Roll right Roll right
Pitch Pitch
Engine Engine
Yaw** Yaw**
Aux*** Aux***
Roll left Roll left
(not assigned) (not assigned)
(not assigned) (not assigned)
Figure 41
