e) Setting the servo stop position

Each servo can only perform a certain maximum servo path and would inevitably hit its mechanical limits in case of
oversteering. "Oversteered servo paths" result when individual servo paths are programmed beyond 100% and/or if
several control commands are mixed in on a servo by various mixers.
To prevent the servos from hitting mechanical limits, you can limit the maximum admissible servo path for each chan-
nel individually.
With this function, you can determine the maximum permissible deflection for the six servo channels. The values may
be adjusted between 0 and 120 and apply to both rotational directions at once.
To choose this function, first switch on the transmitter. When press the "UP"
and "DN" buttons at once twice.
Use the "UP" and "DN" buttons to select servo functions "E1" to "E6".
With the buttons "INC" or "DEC", you can adjust the values between 0 and
120.
For the first flight attempts, the set servo path should remain at 100%.
142
Figure 21
Figure 22
