F) Servo Centre Setting - Reely Hughes Bedienungsanleitung

f) Servo centre setting

With this function, you can adjust the centre setting for all six servos. The standard value is 0 and can be selected
freely between -100 and 100.
Using the complete setting range in the channel centre function may lead to the servos unintentionally
being mechanically blocked or to asymmetric servo paths.
Due to this, you should try to achieve an optimum, mechanically clean control at the standard setting (channel centre
= 0) by relocating the rudder horns or by shortening the linkage. Fine adjustment can be achieved by adjusting the
transmitter.
To choose this function, first switch on the transmitter. Press the "UP" and
"DN" buttons at once three times
Use the "UP" and "DN" buttons to select servo functions "r1" to "r6".
With the buttons "INC" or "DEC", you can adjust the values between -100
and 100.
Figure 23
Figure 24
143
