Put a wedge under spindle and sleeve notch (let go the wheel to lower/lift the spindle).
●
Hold the drill chuck ( 5) with one hand, use the second hand to hit the wedge with a hammer.
●
Drill chuck ( 5) with Morse taper is disassembled.
CLEANING
Never use any caustic agents, or based on petrol or alcohol. Do not allow to dampen the drill press.
●
Keep outer surfaces of the drill press clean, use brush to remove dust and chips from all places where
dirt accumulates.
●
Wipe shields and body with damp, soft cloth (you can use delicate detergent).
●
Wipe drill chuck guard with soft, damp cloth. Be careful not to scratch it (you can use delicate detergent).
All defects should be repaired by service workshop authorized by the manufacturer.
RATED PARAMETERS
Supply voltage
Current frequency
Rated power
Range of spindle rotational speed without load
Number of gear ratios
Protection class
Class of laser device
Maximum laser power
Laser wavelength
Drill chuck range
Maximum steel drilling diameter
Drill chuck holder
Spindle taper
Spindle stroke
Work table dimensions (extended)
Base dimensions
Maximum distance from spindle axis to column surface
Maximum distance of the drill chuck to work table
Maximum distance of the drill chuck to the base
V belts dimensions
Weight
Year of production
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure: Lp = 64.9 dB(A) K = 3 dB(A)
A
Sound power: Lw = 77.9 dB(A) K = 3 dB(A)
A
Vibration acceleration: a = 1.094 m/s
h
Do not dispose of electrically powered products with household wastes, they should be utilized in
proper plants. Obtain information on wastes utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in natural environment. Unrecycled
equipment constitutes a potential risk for environment and human health.
* Right to introduce changes is reserved.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa
Topex) informs, that all copyrights to this instruction (hereinafter Instruction), including, but not limited to, text, photographies, schemes, dra-
wings and layout of the instruction, belong to Grupa Topex exclusively and are protected by laws accordingly to Copyright and Related Rights
Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006 No 90 item 631 with later ammendments). Copying,
processing, publishing, modifications for commercial purposes of the entire Instruction or its parts without written permission of Grupa Topex
are strictly forbidden and may cause civil and legal liability.

TECHNICAL SPECIFICATION

Drill Press
Parameter
2 K = 1,5 m/s 2

ENVIRONMENT PROTECTION

21
Value
230 V AC
50 Hz
500 W
425 – 2545 rpm
12
I
2
< 1mW
λ = 650 nm
1.5 – 16 mm
16 mm
B16
B18
65 mm
240 (340) x 200 mm
380 x 265 mm
125 mm
335 mm
450 mm
508 x 10 / 483 x 10 mm
40 kg
2014
