CAUTION: Adjustments other than described in this manual put in danger of exposition to laser radiation!
CONSTRUCTION AND USE
Drill press is a 1 protection class device designed for drilling holes in objects made of metal or other materials
that are not dangerous to health and are not flammable. It is absolutely necessary to plug the power
cable only to mains socket with protective pin that is connected to electrical circuit with residual current
protection In < 30mA or In = 30mA. Full range of rotational speed is covered by 12-step adjustment
of the V belts position on belt pulleys. Range of use covers metal works and any work from the range of
individual, amateur activities (tinkering).
Use the drill press according to its purpose only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1. Drawer
2. Base
3. Work table
4. Column
5. Drill chuck
6. Wheel for adjustment of drill depth
7. Drill depth scale
8. Laser switch
9. Belt transmission casing
10. Bolts for locking tension of V belts
11. Knob
12. Wheel to lower/lift the spindle
13. Bolt with handwheel of the block of the column clamping ring
14. Column clamping ring
15. Motor
16. Switch
17. Spindle return spring
18. Adjustable laser tip
19. Drill chuck guard
20. Movable part for work table extension
21. Fixing holes
22. Ring for toothed bar fixing
23. Toothed bar
24. Crank for lifting/lowering work table
