• Position new cutting blade so blade teeth and arrow on the blade
match direction of the arrow on the lower guard and upper guard.
• Slide the cutting blade into footplate slot and install on the
spindle so it is well pressed against surface of the inner flange and
centred when seated on its neck.
• Install inner flange washer (9) and tighten the fixing bolt for
cutting blade (10) by turning it clockwise.
• Always put the hexagonal key in its storage place after
replacement of cutting blade.
When installing cutting blade observe correct direction of the
teeth. Arrow on the saw body shows direction of spindle rotation.
Be very careful when holding the cutting blade in hand. Use
protective gloves to provide protection for your hands against
sharp teeth of cutting blade.
All defects should be repaired by service workshop authorized
by the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS
Cordless Circular Saw
Parameter
Battery voltage
Rotational speed (no load)
Bevel cutting range
Max. outer diameter of cutting blade
Inner diameter of cutting blade
At 90° angle
Max. cutting
depth
At 45° angle
Protection class
Weight
Year of production
Graphite Energy+ System Battery
Parameter
Battery
Battery voltage
Battery type
Battery capacity
Ambient temperature range
Charging time for charger 58G002
Weight
Year of production
Graphite Energy+ System Charger
Parameter
Charger type
Supply voltage
Power supply frequency
Charging voltage
Max. charging current
Ambient temperature range
Value
18 V DC
4200 min -1
0° ÷ 45°
150 mm
10 mm
48 mm
36 mm
III
2,475 kg
2017
Value
58G001 58G004
18 V DC 18 V DC
Li-Ion Li-Ion
2000 mAh 4000 mAh
0 0 0 0
4 C – 40 C 4 C – 40 C
1 h 2 h
0,400 kg 0,650 kg
2017 2017
Value
58G002
230 V AC
50 Hz
22 V DC
2300 mA
0 0
4 C – 40 C
18
Charging time of the battery 58G001
Charging time of the battery 58G004
Protection class
Weight
Year of production
NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp and sound power level Lw with measurement uncertainty K
A A
are specified below in this manual, in compliance with EN 60745.
Vibration values a and measurement uncertainty K are
h
determined in accordance with EN 60745 and specified below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745
and can be used to compare power tools. It can also be used for
initial assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead
to higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when
the power tool is switched off and when it is switched on but
not used for working. This way total exposure to vibrations may
be significantly lower. Use additional safety measures to protect
the user against results of exposure to vibrations, such as: power
tool and working tool maintenance, proper hand temperature
conditions, good work organisation.
Sound pressure level: Lp = 79,2 dB (A) K=3dB (A)
A
Sound power level: Lw =90,2 dB (A) K=3dB (A)
A
Vibration acceleration value:
a < 2,5 m/s 2 K= 1,5 m/s 2
h
ENVIRONMENTAL PROTECTION / CE
Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
Li-Ion
* Right to introduce changes is reserved.
"Grupa Topex Spółka z ograniczoną
komandytowa with seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa
Topex) informs, that all copyrights to this instruction (hereinafter Instruction),
including, but not limited to, text, photographies, schemes, drawings
and layout of the instruction, belong to Grupa Topex exclusively and are
protected by laws accordingly to Copyright and Related Rights Act of 4
February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006
No 90 item 631 with later ammendments). Copying, processing, publishing,
modifications for commercial purposes of the entire Instruction or its parts
without written permission of Grupa Topex are strictly forbidden and may
cause civil and legal liability.
1 h
2 h
II
0,300 kg
2017
odpowiedzialnością" Spółka
