Benutzerhandbuch IO-Link Master EtherNet/IP (EIP) und Modbus/TCP
| Beschreibung von Prozessdatenblöcken | Beschreibung von Ausgabe-Prozessdatenblöcken | Ausgabe-Prozessdatenblock:
16-Bit-Datenformat (INT) |
Block nicht aktiviert ist:
Wenn die Optionen Clear Event Code in PDO Block und Include Digital Output(s) in PDO Data Block aktiviert
sind:
12.1.2.2. Ausgabe-Prozessdatenblock: 16-Bit-Datenformat (INT)
Wenn die Optionen Clear Event Code in PDO Block oder Include Digital Output(s) in PDO Data Block nicht
aktiviert sind:
Byte
Bit 7
0
Ereigniscode LSB
1
Ereigniscode MSB
2
PDO-Daten-Byte 0
3
PDO-Daten-Byte 1
..
..
..
..
N+1
PDO-Daten-Byte (N-1)
Byte
Bit 7
0
Ereigniscode LSB
1
Ereigniscode MSB
Einstellungen Digitalausgänge:
2
Bit 1 (0x02) – DI-Einstellung
Bit 3 (0x08) – C/Q-Einstellung
3
0 (nicht belegt)
4
PDO-Daten-Byte 0
5
PDO-Daten-Byte 1
..
..
..
..
N + 3
PDO-Daten-Byte (N-1)
Wort
Bit 15
0
PDO-Daten-Wort 0
1
PDO-Daten-Wort 1
..
..
..
..
N-1
PDO-Daten-Wort (N-1)
Bit 0
Bit 0
Bit 0
85
