28 EnOcean wireless menu (specialist installer)

28 EnOcean wireless menu
(specialist installer)
The PP 45 EO EnOcean module (EnOcean ex-
tension module) can only be taught-in with the
RLS 45 K commissioning software.
With the software, the teaching mode is switched
on and a radio telegram is sent. All radio sensors/
radio switches are taught-in directly on the PP 45
EO. Only the EnOcean module is taught-in on the
master.
Parameters
EnOcean wireless
Teaching mode
EnOcean device list
Teach-out units
PP 45 RC teaching
mode
PP 45 RC unit list
PPB 30 RC teaching
mode
PPB 30 RC units list
1. Activate EnOcean wireless with yes.
2. Set teaching mode to On. The sub-menu
shown above appears. Parameters 2 to 4
serve to teach-in or teach-out the sensors and
radio switch. Parameters 5 to 7 serve to teach-
in or teach-out the PP45 EO on the master
unit PP45 RC.
Before selection of "5. PP 45 RC teaching-
in", it is necessary to define the PP45 RC units
amongst themselves as master-slave.
PP45 RC units only function in pairs and
only with master-slave assignment.
88
Setting value
no, yes
off, on
EEP list
off, on
Teaching-in
PP 45 RC units 1-4
Teaching-in
PPB 30 RC units 1-4
Parameters
Deactivate teaching-in
Manual EEP input
Change name
Teach-out units
Radio components which can be learned-in
You can teach-in up to 8 connected EnOcean
components. PP 45 radio components must sup-
port the EEP protocol. Radio components with the
same EEP no. can be combined with the PP 45
system.
Radio components
which can be learned-
in
EasySens radio switch,
4-channel wall transmit-
ter
Humidity/temperature
sensor
CO2/temperature
sensor
VOC/temperature
sensor*
ViAct (Opus Bridge) 1-
channel flush-mounted
switch
* No EnOcean VOC sensor currently available.
Setting value
→ Following table
bathroom, living room
etc.
All released EnOcean
components are un-
learned
EEP
F6-02-01
A5-04-01
A5-09-08
A5-09-05
D2-01-01
