24 Settings menu (for specialist installers)

24 Settings menu (for specialist
installers)
NOTICE Incorrect settings can cause faults
and malfunctions.
Only authorised installers specialised in ventil-
ation technology may make system and unit
settings at the installer level.
Password entry
After entering the password 6940, you are taken
to the installer level.
Exiting the installer level
1. Close Windows screen.
Installer level — standard display
• Current operating mode
• Current ventilation level
• Faults: visible when fault is present.
• Query: Shows current system values and sys-
tem statuses for the specialist installer.
• Settings: Basic system settings for the special-
ist installer, such as number/selection of unit
types, function selection 230 V input (switching
contact) etc.
• Instructions: Information/PDF instructions for
the specialist installer
• Complete commissioning/maintenance: To
save a commissioning or maintenance protocol.
This includes project data, information regard-
ing the planner, installer and customers as well
as notes. The unit date, all settings and a fault
logbook are automatically input.
• Input/read out data set: To read out or input
the device configurations. This can, for ex-
ample, be sent to the manufacture in case ser-
vicing is needed. Externally created configura-
tion data can be input.
85
