17 SERVICE MENU

17 SERVICE MENU

17.1 Service menu operation

Service mode is cancelled automatically if
no button is pressed for 120 seconds.
Calling up the service menu
Press the and
seconds.
The operating mode LED flashes. They will be
forwarded to the 1st Parameters are forwarded.
Selecting a parameter
You can use
or
ers, see the following chapter.
A permanently lit LED indicates the currently set
parameter.
Changing parameter value
You can set the parameter value with
. The ventilation level LEDs flash when the setting
value is changed.
Saving parameter value
To save, press the buttons
erfor 2 seconds. The ventilation level LEDs are
constantly lit up.
Exiting service menu
Press the and
seconds.
The ventilation unit switches to the specified vent-
ilation level.

17.2 Parameter overview, LEDs

LEDs – Meaning
LED flashes quickly, flashes slowly
(dimmed), lights up
Vertical LEDs flash quickly = change air filter
The following list shows the parameters that can
be set on the RLS 45 K control with the associ-
ated LED displays.
Parameters shown with bold font = RV 2
parameters.
76
buttons together for 5
to select the paramet-
or
and togeth-
buttons together for 5
Par. Function
1 Unit type on RLS
(Fan1, Fan2). With
RV 2 without function.
2 Number of unit pairs,
unit types. With RV 2
without function.
3 Deactivating ventila-
tion level 0
4 Power units, RLS
(on the RS 485 bus)
5 230 VAC input
6 Sensors
7 EnOcean
8 EnOcean Teach
mode. With RV 2
without function.
9 Number of PPB 30 K.
With RV 2 without
function.
10 ModBus settings. AT-
TENTION: The Mod-
Bus interface must
be deactivated for RV
2 units, otherwise the
RV 2 cannot be con-
trolled.
11 ModBus address.
With RV 2 without
function.
12 Plug & Play
LED LED LED
