10.11 Messwertbearbeitung
10.11.1 Neigungskorrektur
TILTCORRECTION [ON|OFF]
Schaltet die Neigungskorrektur ein (ON) oder aus (OFF).
10.11.2 Rechnung, Rechenmodul, Mittelung
COMP [<id>]
COMP <id> MEDIAN <signal> <median data count>
COMP <id> MOVING <signal> <moving data count>
COMP <id> RECURSIVE <signal> <recursive data count>
COMP <id> CALC <factor1> <signal> <factor2> <signal> <offset> <name>
COMP <id> THICKNESS <signal> <signal> <name>
COMP <id> COPY <signal> <name>
COMP <id> NONE
Mit dem COMP Befehl können individuelle Einstellungen für die Datenverarbeitung und Berechnung angezeigt, erstellt,
angepasst oder gelöscht werden. Die Mittelungsfunktionen MEDIAN, MOVING aund RECURSIVE beeinflussen das Aus­
gabesignal <signal>.
Wert Bedeutzung
id 1 ... 10
signal ein Messdaten-Signal (siehe META_COMP)
median data count 3|5|7|9
moving data count 2|4|8|16|32|64|128|256|512|1024|2048|4096
recursive data count 2 .. 32767
factor 1 -32768.0 .. 32767.0 (unit mm)
factor 2 -32768.0 .. 32767.0 (unit mm)
offset -2147.0 .. 2147.0 (unit mm)
name The name of the new signal. Names must contain at least 2 characters, and can contain a maximum of 5 cha­
racters. The following characters are permitted: a-zA-Z0-9_. Each name must begin with an alphabetic cha­
racter: a-zA-Z. Some names are not allowed, e.g. STATISTIC, MASTER, NONE, ALL.
Liste vordefinierter Funktionen:
MEDIAN: Will sort the last <median data count> values and output the middle value. Useful, for example, for elimina­
●
ting spikes.
MOVING: will output an average over the last <moving data count> values.
●
RECURSIVE: averaging uses the previous average value when calculating the new average value. This permits a high
●
degree of smoothing of the measurement values. A higher <recursive data count> will result in a higher amount of
smoothing.
CALC: is used to define custom calculations with one or more signals. The calculation will be performed as follows:
●
(<factor1> * <signal>) + (<factor2> * <signal>) + <offset> The result of the calculation will be placed in a new signal
<name>.
THICKNESS: is used to calculate the difference between two signals. This can also be achieved using a CALC calcula­
●
tion such as: (1 * <signal>) + (-1 * <signal>) + 0
COPY: is used to make a copy of a signal.
●
NONE: is a special option which is used to delete an entry.
●
