Scheppach SC2200PE Original Bedienungsanleitung Seite 36

Service
• Before cleaning, repairing, inspecting or adjusting,
switch off the engine and ensure that all moving
parts have come to a standstill.
• Always ensure that the throttle lever is in the "off"
position. Disconnect the spark plug cable and keep
it away from the spark plug to prevent accidental
start-up.
• Have your machine serviced by qualified personnel.
Use only original spare parts. This ensures that the
machine remains safe.
Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation. Residual risks can be minimised if the
"Safety Instructions" and the "Intended Use" together
with the operating manual as a whole are observed.
• Keep your hands away from the working area when
the machine is in operation.
• Carefully check the area where work is to be done
and keep the work area clean and free of dirt to pre-
vent trip hazards. Work on a level smooth floor.
• During assembly, installation, operation, mainte-
nance, repair or transport, never place any part of
your body in a position where it would be in danger if
movement occurred.
• Never leave the operating position while the engine
is running.
• Always hold the device with both hands during oper-
ation. Always hold the handlebar securely.
• Take particular care when using reverse gear or pull-
ing the machine towards you.
• Be especially careful when working on or crossing
gravel paths, pavements or roads. Always watch out
for hidden dangers and traffic.
Warning! This power tool generates an electromagnet-
ic field during operation. This field can impair active or
passive medical implants under certain circumstances.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
36 | GB
6. Technical data
Transmission
Forward speed
Reverse speed
Total machine width
Sweeping width
Brush diameter
Brush speed
Brush angle
Weight
Drive:
Type of engine
Displacement
Drive wheel tyre size
Support wheel tyre
size
Load speed
Maximum speed
Slope
Engine starter
Power
Fuel
Fuel tank maximum
capacity
Required engine oil
Oil tank maximum
capacity
Battery voltage
Battery capacity
Battery type
Subject to technical changes!
www.scheppach.com
3 forward / 1 reverse
2.5 - 4.3 km/h
2.5 km/h
106 cm
100 cm
350 mm
5 stages /
180 - 350 rpm
-25° / +25°
82 kg
4-stroke motor
173 ccm³
13"x5.00-6
4"x2.6-2.8
2800 rpm.
2900 rpm.
max. 20°
Pull starter /
E-start
3.6 kW / 4.9 HP
Regular grade petrol/
lead-free max.
10% bioethanol
1 l
SAE 10W-30 / 10W-40
0.6 l
12 V
5Ah
Lead acid
