8.1.2.2 Multiturn

Defines the Number of revolutions before the measuring system restarts at zero.
Selection
1 Bit
2 Bit
3 Bit
4 Bit
5 Bit
6 Bit
7 Bit
8 Bit

8.1.2.3 Measuring length

With the parameters Singleturn and Multiturn given above, the Measuring
length in steps can be calculated with the formula below. As the value "0" is already
counted as step, the end value = Measuring length in steps – 1.
Formula:
Measuring length in steps = Number of steps per revolution (Singleturn) * Number of revolutions (Multiturn)
To calculate, the parameters Number of steps per revolution and the
Number of revolutions can be read on the measuring system nameplate.
Lower limit
Upper limit
Default
If a real single-turn is to be realized (256x1, 512x1, 1024x1, 2048x1, 4096x1), the
selection of parameter Singleturn must be agree with the value entered here.
In this case the selection in parameter Multiturn is insignificant.
Printed in the Federal Republic of Germany
02/15/2016
Description
≙ 2 revolutions
≙ 4 revolutions
≙ 8 revolutions
≙ 16 revolutions
≙ 32 revolutions
≙ 64 revolutions
≙ 128 revolutions
≙ 256 revolutions
256
1048576
262144
