The Product Series can accept the following connection cables:
• FEV300-CON-TY2 - Type 2 plug for test adapter EV charging
• FEV300-CON-TY1 - Type 1 plug for test adapter EV charging
Steps for connecting the test adapter to the charging station:
1. Connect the appropriate test cable to the Product.
2. Connect above assembly to the charging station to be tested.
Proper test adapter connection to the charging station is shown in Figures 6,
7, and 8.
Figure 6. Test adapter to Type 2
with panel
Charging Station
Type 2
(with panel mount
socket outlet)
FEV300-CON-TY2
FEV300
Figure 8. Test adapter to Type 1 with fixed cable
FEV300
7
Figure 7. Test adapter to Type 2
FEV300
Charging Station Type 1
(with fixed cable)
FEV300-CON-TY1
with fixed cable
Charging Station Type 2
(with fixed cable)
FEV300-CON-TY2
