3.2.5

LIABILITY

Service activity on electronic equipment in the unit must be provided by Kulzer and/or authorized Kulzer service
partners only and when the equipment is in a safe status (de-energised).
Only use authorised original spare parts and accessories. Avoid other parts as they hide unknown risks.
The operability and safety of the unit are only guaranteed if the necessary tests, maintenance and service workflow is
carried out by Kulzer and/or authorized Kulzer service partners only.
For possible damage coming from a fault/malfunction of the unit due to improper repair, which was not carried out by
Kulzer and/or authorized Kulzer service partners only or in cases where original spare/accessory parts were not used
during a part replacement, Mectron S.p.A. is not liable.
4

Unit description

4.1

Delivery contents

Charging unit

1
2

Hand piece

Light guide, ∅ = 8 mm
3
4 Protective light cone
5 Rechargeable Lithium-ion battery pack
Universal input power supply (100 V – 240 V (
6
6a = Europe type 1
6b = UK
6c = US / JP type 3
NOTE
These components can also be ordered separately.
4.2

Description of the control and operating elements

4.2.1 Hand piece
1 " STAND-BY " button
2 Curing modes LEDs (GREEN)
3 Battery status LED (2-colour: GREEN / YELLOW)
4 Charging unit contacts
Alignment key
5
4.2.2 Alignment key
The alignment key ( 5 ), located at the back bottom part of the hand piece's case, allows the correct
insertion of the hand piece in the charging unit holder.
When inserting the hand piece into the charging unit, the alignment key must be aligned with the
guiding slot positioned inside the charging unit.
A beep confirms that the contacts are in the correct charging position!
4.2.3 Charging unit
Top view elements
Charging unit cover
1
7 Hand piece holder with alignment key and replaceable charging unit contacts
8 Light intensity sensor
9 – GREEN colour LED
Function: It indicates the charging unit is powered up.
10 – 2-colour LED (GREEN / YELLOW)
Function: Light intensity information.
GREEN: Indicates that the light intensity, measured with the built-in light meter is suitable for
effective treatment.
YELLOW : Indicates that the light intensity is insufficient.
type 2
)) including international mains socket adapters:
1x
GB
- 9 -
2x
2x
1x
