Fixing slot stones

5.4 Assembling optional modules

5.4.1 Assembling the motor

Applicable to
Assembling the screw-in hub
Fig. 18: Assembling the screw-in hub
14.10.2021
NOTICE!
The slot stones have a limited screw-in depth!
– Adjust the size and length of the screws to the
slot stones used.
– Never screw the screws in as far as the bottom
of the slot stone(s).
3. Carefully tighten the screw for every slot stone:
Size
40
60, 80, 120 M8
ð The linear unit is assembled on the substrate.
Version
Size
Personnel:
Protective equipment:
Prerequisite:
The electric gear unit and/or motor (if available) are secured
n
against restarting.
1. Place the coupling's screw-in hub (Fig. 18/2) on the timing
belt shaft (Fig. 18/1).
2. Tighten 4 screws (Fig. 18/3) alternating diagonally.
Size
40
60, 80, 120 M8
