9.2.2 RK MonoLine R dynamic load data

Forces and moments
Fig. 43: Schematic diagram
Version
RK MonoLine R 40
Guide carriage length 132 mm
Guide carriage length 212 mm
RK MonoLine R 60
Guide carriage length 186 mm
Guide carriage length 300 mm
RK MonoLine R 80
Guide carriage length 220 mm
Guide carriage length 350 mm
RK MonoLine R 120
Guide carriage length 330 mm
Guide carriage length 530 mm
14.10.2021
F Force [N]
M Moment [Nm]
Permissible forces
[N]
F F
x y
- 1100
- 2800
- 4367
- 9400
Linear unit RK MonoLine R/RK MonoLine Z
Load data > RK MonoLine R dynamic load data
Permissible tor-
ques [Nm]
F M M M
z x y z
35 55
694 14
65 102
102 178
1628 46
195 340
188 327
2509 95
351 611
520 850
5200 280
1010 1780
Technical data
Max. travel speed
[m/s]
5
10
10
10
