3.3.5 Clamping bars

Fig. 10: Clamping bars

3.3.6 Slot stones

Fig. 11: Slot stones

3.3.7 Centring sets

Fig. 12: Centring sets
14.10.2021
The clamping bars are inserted on the side of the guide profile and
are used as a fixing element between the linear unit and the sub-
strate.

Further information:

n Assembling the linear unit with clamping bars
The slot stones are inserted on the underside of the guide profile
and are used as a fixing element between the linear unit and the
substrate.
Further information:
n Assembling a linear unit with slot stones
A Centring set for RK MonoLine R, Z 40
B Centring set for RK MonoLine R, Z 60/80/120
The centring sets are assembled in the holes provided for this pur-
pose on the guide carriage and are used as a positioning aid.
Further information:
n Assembling centring sets
Linear unit RK MonoLine R/RK MonoLine Z
Optional modules > Centring sets
Ä Page 96
Ä Page 97
Ä Page 110
Set-up and function
93
