Rational iCombi Pro Planer-Handbuch Seite 138

11.2.3 UltraVent Plus Typ 6‑1/1 und 10‑1/1
854 [33 5/8]
854 [33 5/8]
11.3.1 UltraVent Typ 6‑2/1 und 10‑2/1
1076 [42 3/8]
1076 [42 3/8]
138
886 [34 7/8]
854 [33 5/8]
Ø75 [Ø3]
1085 [42 3/4]
1076 [42 3/8]
871 [34 1/4]
Ø75 [Ø3]
150 [5 7/8]
207 [8 1/8]
149 [5 7/8]
205 [8 1/8]
