START-UP

Operation elements and display
The device is adjusted once when it is put into operation. After start-up the device operates in
display mode with the top closed.
The display is a two-line LCD display with 2 x 16 characters.
The display has blue background lighting for best readability in all lighting conditions.
®
SmartBox 4 / SmartBox
Heat oil
Fillspace L
After the level indicator has been installed, it can be started up.
Before activating power supply, check whether the SIM card is correctly inserted in the radio
module! (The SIM card must be fully inserted and locked in place).
Activating power supply:
Keep away from the area of the 230 V terminal!
• Activate power supply – the following is displayed alternately
Heat oil
-0L
• After some seconds, "PIN:" appears - now, enter the PIN code for the SIM card (you need
to do this only once). Set the code with PLUS and confirm with ENTER
([+] _ [Enter] [+] _ [Enter] [+] _ [Enter] [+] _ [Enter])
• The device saves the entered PIN code for the next dial-in. It will be available also after a
power failure.
After you have entered the PIN code, the SmartBox
mobile network. This takes approx. 1 - 2 minutes, Display "Netzsuche.." (Mobile network
login). When the dial-up is successful, "Netzsuche.." (Mobile network login) is no longer
displayed.
If login is impossible, the error message "ErrorM5" (see page 28) will be indicated.
In problematic cases, login to the mobile network should be possible after installation of an
external additional antenna. (Accessory: HF antenna with wall bracket and 5 m connecting
cable).
the telecommunication function.
part no. 28 400 57 c
®
4 PRO has the following display:
L
%
0L
100%
By entering the PIN 0000, you can completely deactivate the modem and
SmartBox
The device is adjusted via the three small
blue buttons:
These are located on the
motherboard between the
terminals.
Choosing the language (German, English or
French) in Step "18. Language+Names".
Mobile network
login..
®
automatically attempts to log into the
® ®
4 / SmartBox 4 PRO
