Safety
de
fr
en
Application
nl
ComCube is a communication module for BrainCube controls (Transfero, Compresso, Vento, Pleno PI). Applications
other than those described require prior agreement with Pneumatex. A declaration of conformity is included and certifies
compliance with EU Directives.

Follow the instructions

Installation, operation, maintenance, and disassembly must be carried out as described in these instructions and in
accordance with best practice. For the ComCube DCD TI and DCA TI, the Transfero TI instructions should also be followed.
If anything is unclear, please contact the Pneumatex Customer Service.
Staff
Installation and operating staff must possess the appropriate skills and training.
Place of installation
Access to the place of installation must be restricted to trained and specialised personnel. Electrical power connections must
correspond to the requirements of the equipment.
Observe the parameters
Please refer to the type plate for technical specifications and details of manufacturer, year of construction, and serial number.
The regulations must be observed to ensure temperature and pressure protection, so that the system does not exceed or fall
below the maximum and minimum operating parameters respectively.
Electrical connection
Electrical wiring and connections must be carried out by a skilled professional in accordance with current local regulations.
The system must be shut down before working on any of the electrical components.
Failure to follow these instructions, in particular the safety instructions, may cause loss of functionality, faults or even serious
damage to the ComCube and the electrically connected BrainCube, and may also result in physical injury. If there has been a
failure to comply with these instructions, the manufacturer can no longer accept liability or claims under warranty.

Technical data

The data on the ComCube type plate and the data given below should be compared with the design and system parameters.
There should be no inadmissible deviations. Full technical information is available in the Datasheet (Print) and on the internet
at www.imi-hydronic.com.
Terms
TU :
PA/U/F : ..... kW / 230 V / 50 Hz
IP :
66
40 °C Max. admissible ambient temperature
Connected load/voltage/frequency/ as indicated on type plate
..... EN 60529 protection class, as indicated on type plate
