ComCube DCD
nl
ComCube DCD | DCD TI is an 11-language communication module. It has 6 digital IP inputs for registering and displaying
external volt-free signals and 9 volt-free, individually configurable digital OP outputs. All outputs are individually reversible
from NO (normally open) to NC (normally closed). The graphical 8-line display and the encoder with Scroll and Select
functions make it simple to operate.
ComCube DCD has two main applications:
• Up to 6 programmable external IP inputs and up to 9 OP outputs. For example, external signals can be set for tempera-
tures as commands on the DCD outputs. For individual solutions, please contact our professional advisers.
• OP outputs of a DCD. This avoids the need for expensive software for the interface (examples 1-7). If more than 9 outputs
are required, more than one DCDs (up to 250!) can be connected to one BrainCube.
– I ndividual assignment of BrainCube and ComCube messages on the OP outputs.
– I ndividual switching of the OP outputs of the connected BrainCube control depending on PIS pressure and/or LIS content.
– Status indication (on/off) of ComCube IP inputs and OP outputs.
– I ndication of pressure and content, and switching of the pumps and valves of the connected BrainCube control.
– Monitoring of the connected BrainCube control type.
Installed between the RS 485 of the BrainCube and the building management system (examples 1-6) or the final equipment
for remote monitoring of the BrainCube controls (example 7). There are many other possible applications, which cannot all
be described here.
Parallel connection of ComCube DCD and the BrainCube should consist of up to 4 BrainCube controls and
250 ComCube DCD communication modules.
The total length of the RS 485 data link should be no more than 300 m.
