Servicing
2
f Carefully ease out bottom jaw
Ease out the bottom jaw as illustrated (preferably keeping it
tilted, so that the cutter does not drop into the AT2000 CPK).
CAUTION
Cut hazard. The cutter is extremely sharp.
f Never touch the cutting edge with your ingers.
f Remove blade
.
3
4
5
f Tilt blade holder
5
28
.
2
3
down.
f Remove cable-tie residues.
f Blow cable-tie channel
4
f Flip back blade holder
.
5
f Insert blade
into the recess with the cutting edge
3
facing in.
f If necessary, replace blade
f Insert bottom jaw
.
2
f Tighten screws
.
1

9.5.4 Checking tie advancer

f Switch the power pack CPK OFF.
1
f Push trigger for bandoleer cutter
f Press gate release button
f Open gate
.
1

9.5.5 Changing tie advancer

f Remove screw
.
4
f Swing roller block
up.
5
AT2000 CPK• Operating Instructions • 04-2015 • 106-29004
clear with compressed air.
.
3
to the left.
2
.
3
4
5
2
3
