7.9 Memory menu

1 Refresh memory status
2 Select messages
3 Open created ile
4 Select binding data
5 Export messages and binding data

7.9.1 Refreshing memory status

Number of data records in memory, number of bindings
in memory, and number of error messages.
f Click on the
Refresh button.
; The current values appear in the corresponding ields.

7.9.2 Selecting bindings

Select the binding data to be exported. Possible choices
of binding data for export could be errors or parameter-
setting changes, for example.
It is advisable to set a ilter to restrict the choice if the volume
of data involved is large.
f Restrict the binding data for export by setting a
From binding No. and a

7.9.3 Selecting messages

Select the messages to be exported.
It is advisable to set a ilter to restrict the choice if the volume
of data involved is large.
f Restrict the messages for export by setting a
message No. and a To message No.
AT2000 CPK • Operating Instructions • 04-2015 • 106-29004
5 4
To binding No. as a ilter.
From
as a ilter.
3

7.9.4 Exporting process data

The data are not deleted after they have been exported.
A Data ields have not been initialised
message is issued if the process data have not been
refreshed.
f Click on the
button, à „Refreshing memory
Refresh
status" on page 19.
f Click on Export.
; A Windows pop-up opens.
f Deine the path for saving the CSV ile.
f Click on Save.
; The bindings and messages are exported from the
AT2000 CPK and saved. The progress bar shows progress
of the data transfer in %. When export completes the
name of the saved ile appears in
f Click on open.
; The CSV ile containing the exported data is opened.
HT Data Management
1
2
File loaded.
19
