9.5 Maintenance jobs

9.5.1 Checking top jaw

1
2
f Check top jaw
and top-jaw guide
2
chipping.
f Replace the top jaw if necessary.

9.5.2 Changing top jaw

f Switch the power pack CPK OFF.
f Remove two screws
.
1
f Use a screwdriver to pry top jaw
at the top.
f Work top jaw
down and to the side past bottom
2
jaw .
3
AT2000 CPK • Operating Instructions • 04-2015 • 106-29004
for wear and
1
1
2
3
apart (approx. 3 mm)
2
4
5
6
f Check spring
, pressure pad
5
wear and chipping.
f Angle the new top jaw past the bottom jaw and seat it
in the rail.
f Hold spring
in place during removal and insertion of the
5
top jaw. Make sure that spring
f Tighten two screws
.
1

9.5.3 Check end cap

f Switch the power pack CPK OFF.
f Set the AT2000 CPK in the horizontal position.
f Remove screws
.
1
Servicing
and top-jaw guide for
4 6
is correctly positioned.
5
