DISPLAY MESSAGE
Position tie advancer
1. Operate bandoleer cutter
2. Open gate
Position tie advancer
1. Press Reset button
2. Check position tie advancer
Position tie advancer
Close gate
Error, drum
1. Operate bandoleer cutter
2. Open gate
Error, drum
1. Remove cable-tie residues
2. Press Reset button
Overload
1. Operate bandoleer cutter
2. Open gate
Overload
1. Remove cable-tie residues
2. Press Reset button
AT2000 CPK • Operating Instructions • 04-2015 • 106-29004
POSSIBLE CAUSE
No tie advancer present.
The tie advancer is faulty.
No tie advancer present.
No tie advancer present.
The cable ties are pulled in at an
angle.
The cable ties are pulled in at an
angle.
The drum is blocked.
or
The cable tie is not cut off.
The drum is blocked.
or
The cable tie is not cut off.
SOLUTION
f Push the trigger for the bandoleer cutter to the left.
f Open the gate.
Position of tie advancer appears as the next
message on the display.
f If applicable, carefully remove the cable-tie residues.
f Open the roller block, à „Checking tie advancer" on
page 28.
Position of tie advancer appears as the next
message on the display.
f Check the tie advancer.
f Insert new tie advancer, à „Checking tie advancer" on
page 28.
f Press the Reset button.
Error, gate appears as the next message on the display.
f Close the gate.
f Push the trigger for the bandoleer cutter to the left.
f Open the gate.
f Open the two transparent covers at the gate,
à „Troubleshooting a cable-tie malfunction" on
page 25.
Error, drum appears as the next message on the display.
f If applicable, carefully remove the cable-tie residues.
f Press the Reset button.
Error, gate appears as the next message on the display.
f Close the gate.
f Load new cable ties, à „Loading cable ties" on
page 12.
f Push the trigger for the bandoleer cutter to the left.
f Open the gate.
f Open the two transparent covers at the gate,
à „Troubleshooting a cable-tie malfunction" on
page 25.
or
f Cut off the cable-tie head.
f Check the sensor lever and the end cap for wear.
Error, drum appears as the next message on the display.
f If applicable, carefully remove the cable-tie residues.
f Press the Reset button.
Error, gate appears as the next message on the display.
f Close the gate.
