HT Data Management

7.6 Synchronising time and date

f Click on
Synchronise with PC
; Time and date are synchronised with the PC connected
to the device.
Time and date are saved in the power pack CPK and have to
be rechecked if the power pack CPK is subsequently
changed.

7.7 Binding menu

7.7.1 Changing binding parameter settings

Change the settings for the
parameters.
; The parameter settings are changed and the new
settings are transmitted to the AT2000 CPK.

7.8 Service menu

6

1 Interruption front sensor

2 "Check of binding" setting
3 Send data to tool (AT2000 CPK)
4 Tool access code (AT2000 CPK)
5 Refresh
6 Information for HellermannTyton service

7.8.1 Changing other parameter settings

f Change the settings for the
(level 1-5) and/or Standby time (level 1-3)
f Click on
Send data to
; The parameter settings are changed and the new
settings are transmitted to the AT2000 CPK.
18
time.
Force level and/or Quality
5 4
Interruption front sensor
parameters.
tool.
If force level and/or quality are changed at the
AT2000 CPK (see à „Settings menu" on page 14),
the new values have to be uploaded to the HT Data
Management software.
f Click on the
Fetch data from tool
; The settings from the AT2000 CPK are uploaded to the
HT Data Management software.

7.7.2 Reading binding information

Binding information
binding performed with the AT2000 CPK in connected
status.
3

7.8.2 Changing the access code in the AT2000 CPK

f Enter the new code at
digit number and the default setting is 000.
f Click on
Send data to
; The access code is changed and transmitted to the
AT2000 CPK.
HT Data Management software, à „Change password" on For details of the procedure for changing the password in the
page 20.
button.
shows the process data of the last
1
2
Tool code. The code is a three-
tool.
AT2000 CPK• Operating Instructions • 04-2015 • 106-29004
