5.4.1 Emptying waste container

The waste container has to be emptied after a maximum
of 120 bindings at a bundle diameter of 3 mm.
1
f Pull waste container
in the direction indicated by the
1
arrow and empty the container.
f Close waste container
1
AT2000 CPK • Operating Instructions • 04-2015 • 106-29004
.

6 Service menu

The AT2000 CPK has a Service menu for setting and
checking many functions.
The menu covers:
• Language setting
• Device status
• Settings
• Contact

6.1 Navigation

The controls for navigating in the menu of the AT2000 CPK
are as follows:

Main menu

3
Languages
Status
Settings
Contact
Back
1 Enter button for conirming a selection
2 Select and reset button for selecting a menu
3 Green marker to indicate which menu has been selected
f Press Select button
to select menu
2
f Press Enter button
.
1
; The menu you selected appears on the display.

6.2 Start menu

f Switch the AT2000 CPK ON, à „Switching on" on
page 12.
; Wait approximately 5 seconds for the Start menu to
appear on the display.
Menu
1
1
2 Reset
3
4
5
The green highlight indicates the current force level
Service menu
1
2
of your choice.
3
.
1
