6. Product information

6.4.7 Electrical connection

The following sub-items are only important if you wish to operate the Multilift with
your own control. When using a control not listed under 7.5, the person designing
the system is responsible for observing the applicable standards and directives.

6.4.7.1 Multilift II/Multilift II telescope

Front view of the cable contacts
5 6
2
1
3
Hall sensor and circuitry
D3
E5 bottom
D1
Pin 1
Additional wiring is not required when using our Multilift II controllers.
66
7
8
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
4
Motor +
N/A
+5 V
A
B
N/A
GND
Motor -
D4
+
E5 top
D2
Hall sensor
Pin 8
