6.3.5 Electrical connection

The following sub-items are only important if you wish to operate the Multilift with
your own control. When using a control not listed under 7.5, the person designing
the system is responsible for observing the applicable standards and directives.
6.3.5.1

Multilift I Mono

Plug assignment
Connecting plug assignment
Black
White
Direction of rotation
Polarity
+ -
WH BK
BK WH

6.3.5.2 Multilift I Synchro

Connecting / connection cable for the control (scope of delivery)
Multilift
DIN plug, 8-pin
Direction
Retracts
Extracts
Cable = 2.5 m long
- all wires are looped-through 1 to 1
- there are no junctions
- the plugs cannot be switched
6. Product information
Wiring diagram (intern)
ES
M
D1
Current
Load/N I/A
0 1.0 A
1000 3.0 A
3000* 4.5 A
* the loading capacity applies only for the
model with Fmax. = 3000 N
MultiControl duo / quadro
or
DIN plug, 8-pin
ES
D2
U/V
24 V DC
24 V DC
24 V DC
MultiControl II
Mini-Fit Jr.
