6.4 Multilift II

6.4.1 Variants

The lifting column Multilift II is available in the following variants:
•
Multilift II
•
Multilift II telescope
•
Multilift II impact
•
Multilift II ESD
•
Multilift II telescope ESD
All variants are available as:
•
configuration A (without a milled recess in the outer profile)

6.4.2 Technical specifications

Floor area
Height
Stroke
Weight
Supply voltage
Protection class
Electrical connection
Max. current
consumption
Max. power
consumption
Duty cycle (DC)
Lifetime
Protection class
Continuous sound
pressure level
Lifting speed 8 mm/s
3000 N/
Max. push/pull force
3000 N
Max. push/pull force in 2500 N/
medical applications
Multilift II Multilift II
ESD
312 x 90 mm (L x W)
Lifting range + 203 mm
355 mm, 400 mm, 452 mm, 498 mm
Basic weight: 4.89 kg + (0.016 kg/mm) x stroke
10000 double strokes with a stroke of 500 mm / 1000 N / 16 mm/s
5000 double strokes with a stroke of 500 mm / 3000 N / 8 mm/s
IP 20
16 mm/s 8 mm/s
1000 N/ 3000 N/
1000 N 3000 N
See "Diagram 3:
maximum compressive / tensile force depending on the
lifting length".
1000 N/ 2500 N/
500 N 500 N 500 N
6. Product information
Multilift II
impact
Lifting range +
209 mm
28 V DC
III
Mini-Fit Jr., 8-pin
4.5 A
120 W
DC: S3 10% 20 min.
< 60 dBA
16 mm/s 8 mm/s
1000 N/ 3000 N/
1000 N 3000 N
1000 N/ 2500 N/
500 N 500 N
Multilift II Multilift II
telescope telescope
328 x 90 mm (L x W)
560 mm
650 mm
15 kg
IP 30
8 mm/s 16 mm/s 8 mm/s
3000 N/ 1000 N/ 3000 N/
2000 N 1000 N 2000 N
See "Diagram 5: maximum compressive /
tensile force depending on
the lifting length".
1500 N/ 1000 N/ 1500 N/
500 N 500 N 500 N
ESD
16 mm/s
1000 N/
1000 N
1000 N/
500 N
