Technical Specifications - RK Multilift I Mono Montageanleitung

6. Product information

6.3.2 Technical specifications

Floor area
Height
With extending inner profile
With carriage on the inside
Stroke
Weight
With extending inner profile
With carriage on the inside
Supply voltage (primary)
Protection class
Electrical connection
Max. current consumption
Max. power consumption
Duty cycle (DC)
Lifetime
52
Mono
355 mm, 400 mm, 452 mm, 498 mm (see type plate label)
Special lengths available on request
3,065 kg + (Lift x 0.017 kg/mm)
3,565 kg + (Lift x 0.008 kg/mm)
DIN LS plug 2-pin
DC: S3 10% - duty cycle 10% with 20 min. duration - 2 min. movement - 18 min.
10000 double strokes with a stroke of 500 mm / 1000 N / 16 mm/s
5000 double strokes with a stroke of 500 mm / 3000 N / 8 mm/s
Synchro
260 x 90 mm (L x W)
Lift + 195 mm
Lift + 202.5 mm
28 V DC
III
DIN plug, 8-pin
Mini-Fit Jr., 8-pin
4.5 A
120 W
standby
