6. Product information

Socket assignment

PIN
DIN plug, 8 pin Mini-Fit Jr.
1 + 7
-
3
6
8
-
5
2 + 4
Hall sensor and circuitry
Pin 1+7
Switching using your circuit is not necessary when using our controls for the
Multilift-Synchro.
58
Function
1 Motor up
2 N/A
+ 5V for
3
Hall sensor
Limit switch
4
(internal)
Pulse output
5
Hall sensor
6 N/A
GND for
7
Hall sensor
8 Motor down
ES
D1
Pin 6
Colour
Load/N
Brown
N/A
Red 3000*
Yellow
Grey
N/A
Black
Blue
Hall sensor
ES
M
D2
Pin 2+4
Current
I/A
0 1.0 A 24 V DC
1000 3.0 A 24 V DC
4.5 A 24 V DC
U/V
