SYSTEM MESSAGE INDICATOR LIGHTS
Bed Unplugged:
Bed Charging:
Brake Not Set:
Battery Low:
Call Maintenance:
Locks Enabled:
Note
• The total lockout mechanism blocks the control panel from the siderails, footboard, pendant, touch screen and
head panel (located between the ZOOM
• The brake system can be activated during a Total Lockout but it cannot be removed at any moment during a Total
Lockout .
• The Total Lockout does not affect the Nurse Call (optional), Scale System (optional) and Bed Exit Detection
(optional) functions .
• The parameters of the lock mechanism will be saved if there is a power outage and will start from their original
state when the power returns .
Touch Screen
The Nurse Interface can be activated by pressing one of the function buttons or by pressing on the screen itself . After
2 minutes of inactivity, the LCD intensity will lower to about 10% of its maximal level .
If a submenu is opened and no further action is taken by the user, the LCD will shut off completely after 4 minutes (4
minutes = 2 minutes at 100% intensity + 2 minutes at 10% intensity) .
Return To Table of Contents
1-26
Footboard Operation Guide
This indicator shows that the bed is no longer plugged into a wall socket and
that its power comes from the battery .
This indicator shows that the bed is actually plugged into a power outlet and
that the battery is recharging itself . It is highly recommended not to unplug
the bed as long as this LED is on .
This indicator shows that the brakes are not set, which means that the bed
might move if it is pushed or pulled . This LED can be seen as a reminder
to the personnel that the brake needs to be set before leaving a patient
unattended .
This indicator turns on when the power of the battery is at a low level . When
it does turn on, the bed should be plugged in a wall socket to allow the
battery to be recharged .
This indicator shows when the bed needs repairs or maintenance in regards
to its proper functioning . Most of the time the Call Maintenance indicator
will be illuminated when there is a problem with the electronic part of the
bed system . In this case the appropriate maintenance personnel should be
called .
This indicator shows that a part of the bed (Patient Control Only) is locked
or that a total lockout (All Bed Controls) is activated . Refer to
the Lockouts menu .
®
Option handles) .
2131-209-005 REV B
page 47
