Optional Pendant Operation Guide
OPTIONAL PENDANT CONTROL
A
B
C
D
Button Name
A Channel Up
B Channel Down
C Music Up
D Music Down
E Room Lights
F Reading Light
G TV
H Radio
Nurse Call
I
Fowler Up
J
Fowler Down
K
Gatch Up
L
Gatch Down
M
Return To Table of Contents
1-24
G H
TV
CHANNEL
RADIO
F
E
(All option pendant shown)
Function
Press this button to change to a higher numbered channel .
Press this button to change to a lower numbered channel .
Press this button to turn the music up .
Press this button to turn the music down .
Press this button to turn the room lights on and off .
Press this button to turn the reading light on and off .
Press this button to turn the TV on and off .
Press this button to turn the Radio on and off .
Press this button to communicate with the nurse station .
Press this button to raise the Fowler section of the bed to the
desired angle .
Press this button to lower the Fowler section of the bed to the
desired angle .
Press this button to raise the Gatch section of the bed to the
desired angle .
Press this button to lower the Gatch section of the bed to the
desired angle .
2131-209-005 REV B
QDF27-2073
M
K
I
J
L
