MAIN MENU: SCALE (CONTINUED)

Change Equipment Button

When the "Change equipment" button is pressed
on the Scale screen, Figure 5 .9 will be displayed .
If "Ok" is pressed, the "Do not touch bed" message
will appear as shown in Figure 5 . 1 0 .
When the "Do not touch bed" message disappears,
the "Add/Remove equipment screen appears as
shown in Figure 5 . 1 1 . At this point, the operator
may add or remove equipment as needed and then
presses "Enter" when done .
The "Change equipment success" message will
appear as shown in Figure 5 . 1 1 . 1 when the change
of equipment has been completed successfully .
Note
Negative values cannot be obtained when using the
touch screen menus .
Message
Add/remove
equipment
Please press Enter
when done
Figure 5.11
Return To Table of Contents
1-34
Footboard Operation Guide
Enter Close
2131-209-005 REV B
Message
Change
equipment?
Figure 5.9
Message
Do not
touch bed
Figure 5.10
Message
Change equipment
success
Figure 5.11.1
Ok Cancel
Close
Close
