MAIN MENU: SCALE (CONTINUED)

Weight History Button

When the "Weight History" button is pressed on the
Scale screen, Figure 5 .6 will be displayed .
Each value indicates the time and date that the
weight was taken as well as the weight measured .
The cursor allows the user to go further on each
side to see the values not visible . The arrows only
move by one value at a time .
The "Lb/Kg" button allows the user to change the
measuring value .
The "Store" button allows the user to store the
reading that has just been done .
The "Close" button will bring the user back to the
Scale main screen .
Figure 5 . 7 appears when the user presses on one
of the weights displayed on the graphic in Figure
5 .6 . It shows the weight, the date and the time when
this weight was taken .
You can choose to go back to the previous one
by pressing on "Prev" or to go to the next one by
pressing on "Next" .
Note
The system can keep a maximum of fifty (50)
entries in memory . Any new value added after the
50 th entry will have the first value deleted following
the "First In, First Out" rule .
www.stryker.com
Footboard Operation Guide
Weight History
Unit/Rm :
Weight History
2131-209-005 REV B
350 lbs
320 lbs
340 lbs
Lbs/Kg Reset Store
Figure 5.6
118.4 lbs
JUL. 22, 2008
09:22 AM
Previous
Figure 5.7
375 lbs
340 lbs
Close
Oct. 25,2007 12:00 AM
Next Cancel
Return To Table of Contents
1-33
