MAIN MENU: BED EXIT

Bed Exit
Room #:
Button Name
A Traditional Bed Exit Zone
B Medium Zone
C Small Zone
D Arm
E Disarm
F Volume
Note
• A minimum of 5 lbs is necessary to arm the Bed Exit System .
• During a power outage, the parameters that were set for the detection of the Bed Exit are maintained and saved .
When power resumes, the system will reactivate itself to the same state it was before the power outage . The zone
that was selected before the power outage and the signal CALL NURSE on the wall of the hospital (optional) are
activated .
• The blue color on one of the zones indicates that this is the zone which is actually activated .
• When the zone color turns red, it means that there is a Bed Exit Alarm . In that case the Event Manager window
will appear .
Return To Table of Contents
1-38
Footboard Operation Guide
A B
Arm
D
Function
Press this button to activate the complete zone of detection .
This is the default zone .
Press this button to activate the medium zone of detection .
Press this button to activate the small zone of detection .
Press this button to Arm the Bed Exit Detection System .
Press this button to Disarm the Bed Exit Detection System .
(see page 38) Press this button to access the Volume menu for the alarm .
2131-209-005 REV B
C
Disarm
Oct. 25,2007 12:00 AM
E F
