SIDERAIL MOTION CONTROL PANEL, NURSE CONTROL

E
K
L
(Patient's Right Side Shown)
Button Name
Chair Position
A
B
Flat Position
Trendelenburg
C
Reverse Trendelenburg
D
Fowler Up
E
Gatch Up
F
Foot Up
G
Fowler Down
H
Gatch Down
I
Foot Down
J
Bed Height Up
K
Bed Height Down
L
www.stryker.com

Siderail Operation Guide

A
C
B
H
Function
Press on this button to place the bed in the Chair or Enhanced
Chair position .
Press on this button to place the bed in the Flat position .
Press on this button to place the bed in the Trendelenburg
position .
Press on this button to place the bed in the Reverse Trendelenburg
position .
Press on this button to raise the Fowler section of the bed to
the desired angle .
Press on this button to raise the Gatch section of the bed to the
desired angle .
Press on this button to raise the Foot section of the bed to the
desired angle .
Press on this button to lower the Fowler section of the bed to
the desired angle .
Press on this button to lower the Gatch section of the bed to
the desired angle .
Press on this button to lower the Foot section of the bed to the
desired angle .
Press on this button to raise the height of the bed to the desired
level .
Press on this button to lower the height of the bed to the desired
level .
2131-209-005 REV B
D
I
J
QDF27-2237
Return To Table of Contents
F
G
1-21
