ROTOCLEAR S3
Technical data
Basic data
Dimensions
Field of vision
Connections
Stator
Sealing ring
Rotor
Motor
Rated speed
Rated voltage
Power consumption
Rated current
Current draw
Noise emissions
Overpressure in the connection
box
Air consumption
Air purity
Storage temperature
Operating temperature
Ø290mm(290mm×333mm)×34mm
Ø232mm(minusØ40mminthecentre)
InternalthreadM16×1.5,10mm
PBT, 8 mm safety glass
Ø275mm×3.5mmFPM(Viton)
Alu, PBT, 4 mm safety glass, magnetic ring NdFeB, coating (op-
tional)
Brushless with blocking and reverse polarity protection
max.2300rpm
24 VDC (16–28 V)
24 W (start-up power consumption < 60 W)
1.0A,(start-upcurrentapprox.2.5A)
0.6–0.7 A (upon delivery)
< 65 dB(A) (standard measurement on operator side)
2 – 5 mbar (200 – 500 Pa)
(required for the Rotoclear seal guarantee)
1.2 m³/h (at 200 Pa) (with sealing air connection)
ISO8573-1:2010[3:4:3](requiredforsealingairconnection)
-20°Cto60°Cpermissible
10°Cto60°Cpermissible
