Rotoclear Customer Service.
Specialcase:Retrofitkitforthird-
party devices
A sealing air supply is not provided as standard
when installing the unit using the retrofit kit for
third-party units.
Nevertheless, it must be ensured that the Roto-
clear S3cantakeinairtoprovidetherequiredair
flow.
 When using the Rotoclear S3 standard sup-
plyline,theRotoclear S3canbeoperatedwithor
without a separate sealing air supply according to
thespecificationsinthischapter.
 When using the existing supply line of a
third-partyunit,theconnectionbox(whichisalso
calledtheterminalboxinVisiportunits)locatedat
the end of the protective hose opposite the Roto-
clear S3mustbeequippedwithanairinlet.Todo
so, you can, for example, drill a hole (min. diam-
eter 5 mm) in the housing of the connection box
through which air can be drawn in.
Alternatively, the terminal box can be replaced
with an electric-pneumatic adapter (Fig. 8-C). To
so do, a second M16 to T1/4" adapter, as is pro-
vided on the connection box of Rotoclear S3, is
required in addition to the electric-pneumatic
adapter.
Install it as described in chapter Electrical instal-
lation.
When using the electric-pneumatic adapter, it
is also possible to subsequently connect a seal-
ing air supply to ensure that the unit is sealed in
accordance with the Rotoclear seal guarantee.
Please contact Rotoclear Customer Service.
