ROTOCLEAR S3
Read the additional mounting information
 rotoclear.com/en/rotoclear-S3-assembly-in-
structions
Mounting replacement kit
for S and S2
The Rotoclear S or S2 can be replaced by the
Rotoclear S3usingthereplacementkitforSand
S2 under the conditions mentioned below.
This mounting variant is a special case and
onlyintendedforretrofitting.Ordinarily,theadhe-
sive or screw version should be used.
Checking compatibility
ThereplacementkitforSandS2fitswindows6–
16 mm thick. A spacer ring is available for thinner
panes or sheet metal walls.
For installation, you will require at least 40 mm of
space behind the pane. Please verify this, espe-
cially if the following types are to be replaced:
 Rotoclear S:
• AP1620500
• AP162050030
 Rotoclear S2:
• AP10850500
• AP1085050030
In the above-mentioned types, the power supply
is located on the outside of the machine window.
When using the replacement kit for S and S2, how-
ever, the cabling must be routed to the inside of
the machine disk, as the appliance connection is
located inside the machining area.
If less than 40 mm of space is available behind
the window for installing the replacement kit for S
