Identifying the unit version
5 Measuring channel 4 (IN 10)
0 Not assigned
I IN 10 Measuring module Ci (inductive conductivity)
R IN 10 Measuring module Cr (conductive conductivity)
P IN 10 Measuring module pH/ORP (redox), configured to pH
X IN 10 Measuring module pH/ORP (redox), configured for ORP
6 Expansion slot 1 (IN 11)
0 Not assigned
L Universal input configured for linear scaling
T Universal input configured for temperature (PT100)
C Universal input configured for Cl
7 Expansion slot 2 (IN 12)
0 Not assigned
L Universal input configured for linear scaling
T Universal input configured for temperature (PT100)
C Universal input configured for Cl
8 Expansion slot 3 (IN 13/14/15)
0 Not assigned
N Binary input (3 NO contacts)
9 Expansion slot 4 (OUT 12/13)
0 Not assigned
1 Binary output (1 CO contact)
2 Binary output (2 NO contacts)
3 Binary output (2 x PhotoMos)
4 Binary output (1 TRIAC)
10 Expansion slot 5 (OUT14/15)
0 Not assigned
1 Binary output (1 CO contact)
2 Binary output (2 NO contacts)
3 Binary output (2 x PhotoMos)
4 Binary output (1 TRIAC)
7 Power supply (+/-5 V, 24 V)
11 Expansion slot 6 (OUT16/17)
0 Not assigned
1 Binary output (1 CO contact)
2 Binary output (2 NO contacts)
3 Binary output (2x PhotoMos)
4 Binary output (1 TRIAC)
6 Analogue output (0/4–20 mA)
12 Expansion slot 7 (OUT18/19)
0 Not assigned
1 Binary output (1 CO contact)
2 Binary output (2 NO contacts)
3 Binary output (2x PhotoMos)
