iC2-Micro-Frequenzumrichter
Anwendungshandbuch
2 Übersicht der Anwendungssoftware
2.1 Übersicht der iC2-Micro-Anwendungssoftware
Die Anwendungssoftware ist die Werkseinstellungs- und Standardsoftware, die mit dem iC2-Micro-Frequenzumrichter mitgeliefert
wird. In den folgenden Abschnitten werden ihre Funktionen kurz beschrieben:
• Grundfunktionen
• PID-Regler
• Schutzfunktionen
• Software-Tools

2.1.1 Basic Functions

The application software consists of wide range of basic features which enables the drive to control any application using the iC2–
Micro drive.
2.1.1.1 Reference Handling
References from multiple sources, matching the needs to control the application, are freely definable.
Reference sources are:
• Analog inputs
• Digital inputs either as pulse input.
• Reference from a field bus
• Internal settings
• Local reference from control panel
• Built-in potentiometer on control pannel
Reference signals can be added generating the reference to the frequency converter. The final reference is scaled from -100% to
100%.
2.1.1.2 Two Setups
The frequency converter offers 2 setups. Each setup can be parameterized independently to match various application needs.
Switching between setups is possible during operation, allowing fast change over.
2.1.1.3 Ramps
Linear, Sine ramp, Sine 2 ramps are supported in the frequency converter. The linear ramps provide a constant acceleration. The
Sine ramps provides a non-linear acceleration with soft transition at start and end of the acceleration process.
2.1.1.4 Quick Stop
In some situations, it may be required to stop the application in a quick way. For this purpose, the drive supports a specific decelera-
tion ramp time from the synchronous motor speed to 0 RPM.
2.1.1.5 Limit Rotation Direction
The rotational direction of the motor can be preset to run in 1 direction only (clockwise or counterclockwise), avoiding unintended
rotation direction.
2.1.1.6 Motor Phase Switch
If motor phase cables have been installed in an incorrect order during installation, the rotation direction can be changed. This elimi-
nates the need to change the order of motor phases.
2.1.1.7 Inching with Jogging Modes
The frequency converter has predefined speed settings for use during commissioning, maintenance, or service. The jogging-mode
operation is set at preset speed.
