Plc Out - INFICON Modul1000 Originalbetriebsanleitung

Modulares dichtheitsprüfgerät
Inhaltsverzeichnis

Werbung

9.5.2

PLC OUT

9-13
Technische Daten
F4
+24V
n.c.
Abb. 9-4 PLC Out
PIN 3 - 12: Relaiskontakte, max. 60V DC / 25V AC / 1A
PIN 13, 14: Halbleiterrelais, max. 30V DC / 1A
PIN
1
24V
2
GND
3
4
5
6
7
8
9
10
11
12
13
14
15
16
